Domino Led pitch 3.9 from outside (€/sqm)
DDLEDOUT1
Made to order
2 years
DDLEDOUT1
| Product code | DDLEDOUT1 |
|---|---|
| Resolution | 128x256 / 128x192 px |
| Brightness | 5000~6000 nit |
| Encumbrance | 1000x500x90 / 750x500x90 mm |
| Weight | 20 Kg |
Fill in this form to be contacted
Win potential customers
LED panels have an exceptional image quality. Can be customized to fit specific space requirements, giving customers an even more immersive experience.
Create the shape you want
Contact our sales department through the form below and request a quote for a ledwall of the size you want, complete with control unit and assembly structure.
Die-cast aluminium modules
High precision cutting for high uniformity.
Super light modules, 29kg/mq, resulting in optimization of labor and transport costs.
Eye-catching images
Excellent heat dissipation for high definition and color sharpness.
Black LEDs for very high color contrast.
DHR (Deformation and High-temperature Resistance) masks allow to eliminate any "protrusions" and stains.
Dual Backup with high brightness like never before
Supports backup power and receive cards to ensure high stability, and without compromising brightness.
IP65 High protection
IP65 both front and rear.
Possibility to increase the degree of IP (IP66).
Magnetic cards with safety cables.
Creative compositions
Possibility of composing the screen with different module sizes.
Customization with 45° module cut for continuous angles without interruption.
Mixed composition with 45° modules and rounded-corners modules.
Easy installation and maintenance
Supports direct wall mounting with 90 mm screen thickness.
Optional quick-release hook blocks for quick installation.
Both front and rear maintenance.
Universal boards (dx-sx) reduce spare parts costs.
Supported intelligent module functionality for easy pixel diagnostics and auto-re-configuration after board replacement.
Details
Protection IP66
Horizontal/vertical viewing angle 140°
Refresh rate 3840HZ
Average power consumption 230W/m 2
Operating temperature/humidity - 20C° + 60°C
2 years warranty ex-factory
