Domino Led pitch 4.8 from outside (€/sqm)

Product code:
DDLEDOUT2
Availability:
Made to order
Warranty:
2 years
MPN:
DDLEDOUT2
Availability: In stock
SKU:
DDLEDOUT2
As low as
€2,562.00 €2,100.00

More Information
Product code DDLEDOUT2
Resolution 104x208 / 104x156 px
Brightness 5000~7000 nit
Encumbrance 1000x500x90 / 750x500x90 mm
Weight 25 Kg


Rellene este formulario para ser contactado



Win potential customers

LED panels have an exceptional image quality. Can be customized to fit specific space requirements, giving customers an even more immersive experience.


Create the shape you want

Contact our sales department through the form below and request a quote for a ledwall of the size you want, complete with control unit and assembly structure.

Die-cast aluminium modules

High precision cutting for high uniformity.
Super light modules, 29kg/mq, resulting in optimization of labor and transport costs.

Eye-catching images

Excellent heat dissipation for high definition and color sharpness.
Black LEDs for very high color contrast.
DHR (Deformation and High-temperature Resistance) masks allow to eliminate any "protrusions" and stains.

Dual Backup with high brightness like never before

Supports backup power and receive cards to ensure high stability, and without compromising brightness.

IP65 High protection

IP65 both front and rear.
Possibility to increase the degree of IP (IP66).
Magnetic cards with safety cables.

Creative compositions

Possibility of composing the screen with different module sizes.
Customization with 45° module cut for continuous angles without interruption.
Mixed composition with 45° modules and rounded-corners modules.

Easy installation and maintenance

Supports direct wall mounting with 90 mm screen thickness.
Optional quick-release hook blocks for quick installation.
Both front and rear maintenance.
Universal boards (dx-sx) reduce spare parts costs.
Supported intelligent module functionality for easy pixel diagnostics and auto-re-configuration after board replacement.

Details

Protection IP65
Horizontal/vertical viewing angle 140°
Refresh rate 3840HZ
Average energy consumption 350W/m 2
Operating temperature/humidity - 20C° + 60°C
2 years warranty ex-factory
